Antec VP550 Plus 550W ATX 80 Plus Certified Non-Modular Active PFC Power Supply

Brand: Antec
Product Code: 204
Availability: In Stock
Status: Brand New
Warranty: One Year RTB Warranty
Manufacturer Url: https://www.antec.com/product/power/vp550-plus

Price: $98.90 GST Inclusive $86.00 GST Exclusive

Antec VP Plus Series VP550 Plus 550W ATX12V / EPS12V 80 Plus Certified Non-Modular Active PFC Power Supply




  • The new generation of VP550 PLUS is crafted for quality, performance and incredible value

  • This entry-level solution is rated for 550W, saving energy through its high efficiency of up to 85% efficient and is 80 Plus 230V standard certified

  • Saving energy through its high efficiency of up to 85% efficient and is 80 PLUS Standard certified.

  • The VP PLUS series utilizes active PFC, and provides efficiency during max and low loads—living up to the performance standards that we are known for.



3 Years Warranty Return To Base.


SPECIFICATIONS

Product Name VP550 PLUS
Model Name X3000A101-18
Modular Non-Modular
Dimension (W x L x H) 140(D)*150(W)*86(H)
Warranty 3 years
Input Voltage 100-240 VAC ±10%
Input Current 8A-4A
Input Frequency Range 47Hz-63Hz
PFC Active PFC (>0.9 typical)
Power Good Signal 100-500ms
Efficiency 85% Typically
Protection UVP/OVP/SCP/OPP/NLO
Output Capacity 550W
Regulatory cTUVus/TUV/CB[IEC62368 Compliant] /CE/FCC
Fan 120mm Silent Fan
Certifications 80 Plus
Connector 1 x MB 24(20+4) Pin
1 x 8(4+4) Pin EPS 12V
2 x 8(6+2) Pin PCI-E
7 x SATA
2 x Molex
1 x FDD
Net Weight 1.78 Kgs
Gross Weight 2.20 Kgs
