Brand: Antec
Product Code: 204
Availability: In Stock
Status: Brand New
Warranty: One Year RTB Warranty
Manufacturer Url: https://www.antec.com/product/power/vp550-plus
Product Code: 204
Availability: In Stock
Status: Brand New
Warranty: One Year RTB Warranty
Manufacturer Url: https://www.antec.com/product/power/vp550-plus
Price: $98.90 gst Inclusive $86.00 gst Exclusive
Antec VP Plus Series VP550 Plus 550W ATX12V / EPS12V 80 Plus Certified Non-Modular Active PFC Power Supply
- The new generation of VP550 PLUS is crafted for quality, performance and incredible value
- This entry-level solution is rated for 550W, saving energy through its high efficiency of up to 85% efficient and is 80 Plus 230V standard certified
- Saving energy through its high efficiency of up to 85% efficient and is 80 PLUS Standard certified.
- The VP PLUS series utilizes active PFC, and provides efficiency during max and low loads—living up to the performance standards that we are known for.
3 Years Warranty Return To Base.
SPECIFICATIONS
Product Name | VP550 PLUS |
Model Name | X3000A101-18 |
Modular | Non-Modular |
Dimension (W x L x H) | 140(D)*150(W)*86(H) |
Warranty | 3 years |
Input Voltage | 100-240 VAC ±10% |
Input Current | 8A-4A |
Input Frequency Range | 47Hz-63Hz |
PFC | Active PFC (>0.9 typical) |
Power Good Signal | 100-500ms |
Efficiency | 85% Typically |
Protection | UVP/OVP/SCP/OPP/NLO |
Output Capacity | 550W |
Regulatory | cTUVus/TUV/CB[IEC62368 Compliant] /CE/FCC |
Fan | 120mm Silent Fan |
Certifications | 80 Plus |
Connector | 1 x MB 24(20+4) Pin |
1 x 8(4+4) Pin EPS 12V | |
2 x 8(6+2) Pin PCI-E | |
7 x SATA | |
2 x Molex | |
1 x FDD | |
Net Weight | 1.78 Kgs |
Gross Weight | 2.20 Kgs |
