SilverStone ST40F-ES230 Strider Essential 400W 80 Plus ATX PC Power Supply Low Noise 120mm Fan

Brand: SilverStone
Product Code: 1525
Availability: In Stock
Status: Brand New
Warranty: One Year RTB Warranty
Manufacturer Url: https://www.silverstonetek.com/product.php?pid=674&area=en

Price: $69.00 gst Inclusive $60.00 gst Exclusive

  Add To Cart

Add to Wishlist

Add to Compare


ST40F-ES230





￭ High efficiency with 80 PLUS certification



￭ 24/7 continuous power output with 40℃ operating temperature



￭ Class-leading single +12V rail



￭ Active PFC Circuitry



￭ PCI-E 8pin and PCI-E 6pin connector support



￭ Silent running 120mm fan with 18dBA



SPECIFICATIONS

Model No.
SST-ST40F-ES230
Max. DC Output
400W
Power density
221W per liter

Load Range

 +3.3V +5V +12V +5VSB -12V
Max.(Amps)
 17A 16A 30A 2.5A 0.3A
Peak (Amps)
 / / / / /
Min.(Amps)
 0A 0A 0A 0A 0A
Range (%)
 ±5% ±5% ±5% ±5% ±10%
Line Reg.(%)
 ±1% ±1% ±1% ±1% ±1%
Ripple(mVp-p)
 50mV 50mV 120mV 50mV 120mV
Color
Black（Lead-Free Paint）
Combined +3.3V & +5V
100W
Combined +12V
360W
Input Voltage
180V~264V
Input Frequency Range
47Hz~63Hz
PFC
Active PFC（PF>0.9 at full load）
Efficiency
82% ~ 85% at 20% ~ 100% loading
MTBF
100,000 hours
Operating temperature
0°C ~ 40°C
Protection
Over power protection
Over voltage protection
Short circuit protection
Connectors
1 x 24 / 20-Pin motherboard connector（500mm）
1 x 8 / 4-Pin EPS / ATX 12V connector（750mm）
2 x 8 / 6-Pin PCIE connector（"500mm / 150mm" x 2）
4 x SATA connector（"500mm / 150mm" x 2）
2 x 4-Pin Peripheral connector（500mm / 150mm / 150mm / 150mm）
1 x 4-Pin Peripheral connector（500mm / 150mm / 150mm）
1 x 4-Pin Floppy connector（500mm / 150mm / 150mm / 150mm）
Cooling System
Single 120mm silent fan
Form factor
Noise Level
18 dBA minimum
Dimension
150 mm (W) x 86 mm (H) x 140 mm (D)
5.91" (W) x 3.39" (H) x 5.51" (D)
Weight
1.26 kg
Certification
80 PLUS
Other
GPU Support list
Compatible with ATX12V v2.4
