KF552C36BBEAK2-32 Fury Beast RGB EXPO 32GB DDR5 RGB Desktop RAM Kit (2x 16GB) 5200MT/s DDR5 CL36 DIMM

KF552C36BBEAK2-32

32GB (16GB 2G x 64-Bit x 2 pcs.)

DDR5-5200 CL36 288-Pin DIMM Kit

DESCRIPTION

Kingston FURY KF552C36BBEAK2-32 is a kit of two 2G x 64-bit

(16GB) DDR5-5200 CL36 SDRAM (Synchronous DRAM) 1Rx8,

memory module, based on eight 2G x 8-bit FBGA components per

module. Each module kit supports AMD® EXPO v1.0 and

Intel® Extreme Memory Profiles (Intel® XMP) 3.0. Total kit

capacity is 32GB. Each module has been tested to run at

DDR5-5200 at a low latency timing of 36-40-40 at 1.25V. The

SPDs are programmed to JEDEC standard latency

DDR5-4800 timing of 40-39-39 at 1.1V. Each 288-pin DIMM

uses gold contact fingers. The JEDEC standard electrical

and mechanical specifications are as follows:

SPECIFICATIONS

CL(IDD)  40 cycles

Row Cycle Time (tRCmin)  48ns(min.)

Refresh to Active/Refresh  295ns(min.)

Command Time (tRFCmin)

Row Active Time (tRASmin)  32ns(min.)

UL Rating  94 V - 0

Operating Temperature  0oC to +85oC

Storage Temperature -55oC to +100oC

FEATURES

• Power Supply: VDD = 1.1V Typical

• VDDQ = 1.1V Typical

• VPP = 1.8V Typical

• VDDSPD = 1.8V to 2.0V

• On-Die ECC

• Height 1.66” (42.23mm), w/heatsink
