ASUS PRIME H510M-E Intel H510 Chipsets LGA1200 M.2 USB 3.2 Type-A DP/HDMI/VGA COM Port RGB MicroATX MB

Brand: ASUS
Product Code: 100610
Availability: In Stock
Status: Brand New
Warranty: One Year RTB Warranty
Manufacturer Url: https://www.asus.com/Motherboards-Components/Motherboards/PRIME/PRIME-H510M-E/

Price: $144.90 GST Inclusive $126.00 GST Exclusive

PRIME H510M-E



Intel® H510 (LGA 1200) micro ATX motherboard with PCIe 4.0, 32Gbps M.2 slot, Intel® 1 Gb Ethernet, DisplayPort, HDMI, D-Sub, USB 3.2 Gen 1 Type A, SATA 6Gbps, COM header, RGB header




  • Intel® LGA 1200 socket: Ready for 11th and 10th Gen Intel® Processors

  • Ultrafast connectivity: PCIe 4.0, 32Gbps M.2 slot, Intel® 1 Gb Ethernet and USB 3.2 Gen 1 Type-A

  • Comprehensive cooling: PCH heatsink and Fan Xpert

  • 5X Protection III: Multiple hardware safeguards for all-round protection


CPU



Intel® Socket LGA1200 for 11th Gen Intel® Core™ Processors & 10th Gen Intel® Core™, Pentium® Gold and Celeron® Processors



Supports Intel® 14 nm CPU



Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0**



* Refer to www.asus.com for CPU support list.



** Intel® Turbo Boost Max Technology 3.0 support depends on the CPU types.



Chipset



H510



Memory



Memory Channels:2DDR4 (Dual Channel)

Max Memory Size:64GB



DDR4 3200(OC)/2933/2800/2666/2400/2133 MHz Non-ECC, Un-buffered Memory*



Dual Channel Memory Architecture



Supports Intel® Extreme Memory Profile (XMP)



* 10th Gen Intel® Core™ i7/i9 processors support 2933/2800/2666/2400/2133 natively, others will run at the maximum transfer rate of DDR4 2666MHz.



* 11th Gen Intel® processors support 2933/2800/2666/2400/2133 natively.



* Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists), and memory frequency support depends on the CPU types.



Graphics







1 x DisplayPort 1.4

1 x D-Sub

1 x HDMI™ 1.4 / 2.0***



* Graphics specifications may vary between CPU types.



** Intel® 11th & 10th Gen processors support DisplayPort 1.4 with max. resolution of 4096 x 2304 @60Hz. Please refer to www.intel.com for any update.



*** Only Intel® 11th Gen processors support HDMI™ 2.0 with max. resolution of 4K@60Hz, others will only support HDMI™ 1.4 with max. resolution of 4K@30Hz. Please refer to www.intel.com for any updates.



Expansion Slots Intel® 11th & 10th Gen Processors



Expansion Slots



Intel® 11th & 10th Gen Processors



1 x PCIe 4.0/3.0 x16 slot



- Intel® 11th Gen processors support PCIe 4.0 x16



- Intel® 10th Gen processors support PCIe 3.0 x16



Intel® H510 Chipset



2 x PCIe 3.0 x1 slot



Storage



Supports 1 x M.2 slot and 4 x SATA 6Gb/s ports



Intel® H510 Chipset



M.2 slot (Key M), type 2242/2260/2280 (supports PCIe 3.0 x4 & SATA modes)



4 x SATA 6Gb/s ports



* The M.2 slot shares bandwidth with the SATA6G_2 port. When a device in SATA mode is installed on the M.2 slot, the SATA6G_2 port cannot be used.



Ethernet



1 x Intel® I219-V 1Gb Ethernet



ASUS LANGuard



USB







Rear USB:Total 4 ports



2 x USB 3.2 Gen 1 ports (2 x Type-A)



2 x USB 2.0 ports (2 x Type-A)



Front USB:Front USB (Total 6 ports)



1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports



2 x USB 2.0 headers support additional 4 USB 2.0 ports



Audio



Realtek ALC897/887 7.1 Surround Sound High Definition Audio CODEC*



- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking



- Supports up to 24-Bit/192 kHz playback



Audio Features



- Audio Shielding



- Premium Japanese audio capacitors



- Dedicated audio PCB layers



* A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output.



Back Panel I/O Ports



2 x USB 3.2 Gen 1 ports (2 x Type-A)



2 x USB 2.0 ports (2 x Type-A)



1 x DisplayPort



1 x D-Sub port



1 x HDMI™ port



1 x Intel® I219-V 1Gb Ethernet port



3 x Audio jacks



1 x PS/2 Keyboard (purple) port



1 x PS/2 Mouse (green) port



Intrernal I/O Connectors



Fan and Cooling related



1 x 4-pin CPU Fan header



1 x 4-pin Chassis Fan header



Power related



1 x 24-pin Main Power connector



1 x 8-pin +12V Power connector



Storage related



1 x M.2 slot (Key M)



4 x SATA 6Gb/s ports



USB



1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports



2 x USB 2.0 headers support additional 4 USB 2.0 ports



Miscellaneous



1 x RGB header



1 x Clear CMOS header



1 x COM Port header



1 x Front Panel Audio header (AAFP)



1 x S/PDIF Out header



1 x Speaker header



1 x SPI TPM header (14-1pin)



1 x 10-1 pin System Panel header



Special Features



ASUS 5X PROTECTION III



- DIGI+ VRM



- LANGuard



- Overvoltage Protection



- SafeSlot Core



- Stainless-Steel Back I/O



ASUS Q-Design



- Q-DIMM



- Q-Slot



ASUS Thermal Solution



- Aluminum heatsink design



ASUS Lighting Control



- RGB header



Software Features



ASUS Exclusive Software



Armoury Crate



AI Suite 3



- Performance And Power Saving Utility



  TurboV EVO



  EPU



  DIGI+ VRM



  Fan Xpert



- EZ update



ASUS CPU-Z



AI Charger



DAEMON Tools



Norton Anti-virus software (Free Trial version)



WinRAR



UEFI BIOS



ASUS EZ DIY



- ASUS CrashFree BIOS 3



- ASUS EZ Flash 3



- ASUS UEFI BIOS EZ Mode



BIOS



128 Mb Flash ROM, UEFI AMI BIOS



Manageability



WOL by PME, PXE



Accessories



Cables



2 x SATA 6Gb/s cables



Miscellaneous



1 x I/O Shield



1 x M.2 ANCHOR



Installation Media



1 x Support DVD



Documentation



1 x User manual



1 x ACC Express Activation Key Card



Operating System



Windows® 10 64-bit



Form Factor



microATX

22.6cm x 20.3cm
