Blazer Pro 1000VA/600W Line Interactive UPS , LCD Screen 12V/7Ah battery 3 AC Output

Brand: Blazer
Product Code: 446
Availability: In Stock
Status: Brand New
Warranty: One Year RTB Warranty
Manufacturer Url:

Price: $158.70 Gst Inclusive $138.00 Gst Exclusive

MFC: 9C39-63184-Q0P



Blazer Pro 1000VA/600W Line Interactive UPS LCD Screen 12V/7Ah battery 3 Output Powered by EATON UPS Factory



MODEL Blazer Pro 400 Blazer Pro 600 Blazer Pro 800 Blazer Pro 1000 Blazer Pro 1400 Blazer Pro 2000



CAPACITY VA/W 400VA/240W 600VA/360W 800VA/480W 1000VA/600W 1400VA/840W 2000VA/1200W



INPUT Voltage 110/115/120VAC or 220/230/240VAC



Voltage Range 81-145VAC / 162-290VAC



OUTPUT Voltage 110/115/120VAC or 220/230/240VAC



Voltage Regulation (Battery Mode) ?10% ?5% At load < 50%



Frequency 50Hz or 60Hz



Frequency Regulation (Battery Mode) +/-1 Hz



Output Waveform Modified Sinewave



BATTERY Battery Type and Number 12V/4.5AH x 1 pc 12V/7AH x 1 pc 12V/9AH x 1 pc 12V/7AH x 2 pc 12V/9AH x 2 pc



Back up Time



(at a PC load with 15" monitor) 8-12 minutes 15-20 minutes 25-30 minutes 40 minutes 45 minutes



Recharge Time 8 hours to 90% after complete discharge 10 hours to 90% 6 hours to 90%



TRANSFER TIME Typical 2-6ms 4-8ms



INDICATOR AC Mode Green lighting The 1st green LED lighting.



The 2nd to 5th green LEDs gradually lighting indcating load level



Battery Mode Green flashing The 1st green LED flashing.



The 2nd to 5th green LEDs gradually lighting indcating battery capacity



Fault - Red LED lighting



AUDIBLE ALARM Battery Mode Sounding every 10 seconds



Low Battery Sounding every second



Overload Sounding every 0.5 second



Battery Replacement Sounding every 2 seconds



Fault Continously sounding



PROTECTION Full Protection Discharge, overcharge and overload protection Discharge, overcharge, short-circuit and overload protection



PHYSICAL Dimension, DXWXH (mm) 330 x 100 x 140 405 x 205 x 145



Net Weight (kgs) 5 6 6.5 9.6 9.7 9.8



ENVIRONMENT Operating Environment 0-40?C, 0-90 % relative humidity (non-condensing)



Noise Level Less than 40dB Less than 45dB



INTERFACE Smart RS-232 Support Windows family, Linux, IBM Aix, Sun Solaris, Compaq True64, UnixWare, FreeBSD, HP-UX, and MAC



USB Option Windows family and MAC OS



One Year Return To Base Warranty
