Shuttle XPC SG41J1 PLUS Barebone System LGA775 G41 DDR3 VGA/DDVI 250W PSU

Brand: Shuttle
Product Code: 312
Availability: In Stock
Status: Brand New
Warranty: One Year RTB Warranty
Manufacturer Url: http://us.shuttle.com/barebone/Models/SG41J1_PLUS.html

Price: $253.00 Gst Inclusive $220.00 Gst Exclusive

Shuttle SG41J1 PLUS Barebone System, Black, LGA775, Intel G41 + ICH7, 1333MHz FSB, 2 x DDR3 DIMM slots (Max 8GB, Dual Channel), Built-in Intel X4500, 1 x PCIEx16, 1x PCI, 1x ATA, VGA+DVI output, 250W PSU, support 2 x 3.5` bay, 1 x 5.25` bay, 3 x SATA connectors, 6 x USB, Realtek ALC662 5.1 channel High Definition Audio, Gigabit LAN

Specifications

FORM FACTORShuttle Form Factor / Support mini-ITX also
PROCESSORIntel Core 2 Quad、 Core 2 Duo,Dual-Core,Celeron 400 serial support
FSB 800/1066/1333*MHz support
(*Native support)
CHIPSETIntel G41 + ICH7
MEMORY2 x 240 pin DDR3 DIMM slots,4GB per DIMM (Max 8GB)
Dual Channel DDR3 800/1066
VGABuilt-in Intel Intel X4500
DirectX 10 Support
DVI resolution 2048 x 1526
AUDIOIDT 92HD89C
5.1 channel High Definition Audio
ETHERNETMarvell 88E8057
IEEE 802.3u 100Base-T specification revision 1.0
100Mb/s and 1Gb/s operation
Support Wake-On-LAN function
STORAGE INTERFACE(3) 3.0Gb/s bandwidth SATA II
(1) Ultra DMA/100 IDE channel
ONBOARD CONNECTORS(3) SATA connectors
(1) ATA100 bus IDE connector
(2) 1x5 pin USB 2.0 header
(2) Serial Port Header
(1) ATX main power connector
(1) ATX 12V power connector
(2) set 4pin fan connectors
FRONT PANEL(2) USB 2.0 ports
(1) Microphone-In
(1) Earphone-Out
Power-On button
Power LED
HDD LED
BACK PANEL(1) PCI-E x16 slot
(1) PCI slot
(1) RJ45 Gigabit LAN port
(1) DVI-D VGA port
(4) USB 2.0 ports
(1) PS/2 keyboard port
(1) PS/2 mouse port
(1) Line in port
(1) Line out port
(1) MIC in port
(1) Clear CMOS button
(2) Wireless Antenna fixture
EXPANSION BAY(2) 3.5` bay
(1) 5.25` bay
DIMENSIONS325(L) x 215(W) x 204(H) mm
POWER250W
Input:100-240V AC
ACCESSORIESXPC Multilanguage Quick User Guide
XPC CD Driver (XP and Vista 32 / 64 bit and Win7 32/ 64 bit)
1* Power cord
1* IDE cable (pre-install)
1* SATA cable (pre-install)
1* 4 pin to SATA power cable

One year Return To Base Warranty
