AMD AM4 Ready. (NOTE: Refer to FM2+/FM2/FM1/AM3+/AM3/AM2+/AM2 for the manuals)

Equipped with multiple clips to support Intel LGA1155/1156/775 and AMD AM4/AM3/AM2+/AM2/K8.

2 sintered metal powder heatpipes directly contacting the CPU surface for removing heat and eliminating chances of overheating.

Specialized aluminum heatsink construction for efficient heat dissipation.

TPE fan housing designed to absorb operating vibration and reduce fan noise.

Features

1，2 sintered metal powder heatpipes directly contacting the CPU surface for removing heat and eliminating chances of overheating.

2，Specialized aluminum heatsink construction for efficient heat dissipation.

3，TPE fan housing designed to absorb operating vibration and reduce fan noise.

Spec

Overall Dimension： 119X75X112mm

Heat sink size： 85X57.2X112mm

Fan Dimension： 80X80X25mm

Net Weight： 258g

Bearing Type： Hydro Bearing

Rated Voltage： 12VDC

Operating Voltage： 10.8～13.2VDC

Started Voltage： 7VDC

Rated Current： 0.12±10%A

Power Input： 1.44W

Fan Speed： 2200±10%RPM

Max. Air Flow： 25.13CFM

Noise： 24.7dB(A)

Fan Connector： 3-pin

CPU compatible

Intel Socket 95W

LGA1156/1151/1150/1155/LGA775

Core i7/i5/i3

Core 2 Quad/Duo

Pentium/Pentium G

Celeron/Celeron G



AMD Socket 100W

AM4/AM3+/AM3/AM2+/AM2/FM2+/FM2/FM1

（Note: To send an Intel bracket, AMD installation requires the motherboard's own bracket.）

Ryzen

APU A12/A10/A8/A6/A4

FX 8/6/4-Core

Phenom II X6/X4/X3/X2

Athlon II X4/X3/X2

Athlon X4
