DQ750ST is certified with 80 plus Gold with 87% to 90% electrical efficiency enabling lower heat generation and lower operating cost. Outstanding and stable performance makes it one of the greatest PSU of Deepcool. DQ750ST is capable of providing 750W continuous electrical supply under 50?. It is equipped with 120mm speed adjustable silent fan. DQ750ST is sure to be one of the most ideal equipment for gamers.

Features

• Compliant Intel ATX12V v 2.31


• 80 PLUS® GOLD certified – Up to 87~90% efficiency (20~100% loading)


• 120mm FDB Bearing PWM fan with specially designed fan-blade, enjoys higher wind-pressure, super silent and excellent performance


• The longer flat cable, exellent for cable management and increases the cooling capability of system


• Double-Layer EMI Filter protects from electromagnetic interference & restrains noise


• Intelligentized eco-friendly chipset, consume < 0.3W in its off-mode, compliant Erp standard


• CircuitShield™ — OVP, UVP, SCP, OPP


• Compliant Multi-Way SLI / CrossFire + Multi-Core CPUs


• High reliability with an MTBF of at least 120,000 hours of use

Specifications

• Model: DQ750ST


• Type: ATX 12V V2.31


• Certifications: 80PLUS GOLD


• Dimension: 150×140×86mm (W x L x H)


• Output Capacity: 750W


• Input Voltage: 100~240V


• Input Current: 10A/5A


• Input Frequency Range: 47~63Hz


• Fan Size: 120mm FDB FAN


• PFC: Active PFC (>0.99)


• Power Good Signal: 100–500ms


• Hold Up Time: >16ms


• Efficiency: 90% Under Typical Load


• Protection: OVP / UVP / SCP / OPP /

Operation Temperature:** 0~40°C

• Regulatory: CE / FCC / CCC / CB / EAC / TUV


• MTBF: 120,000 Hours
