Sapphire Pulse Radeon RX570 8G GDDR5 Graphics Card ITX DVI-D/HDMI/DISPLAY PORT 6 Pin power 170mm Length, Max 3 Displays

Brand: Sapphire
Product Code: 1244
Availability: In Stock
Status: Brand New
Warranty: One Year RTB Warranty
Manufacturer Url: https://www.sapphiretech.com/en/consumer/pulse-rx-570-itx-8g-g5

Price: $262.20 Gst Inclusive $228.00 Gst Exclusive

PULSE RX 570 8G G5 ITX




  • Engine Clock: Up to 1244 MHz (Boost)

  • Memory: 8GB GDDR5 6000 MHz Effective

  • 2048 Stream Processors

  • ITX Form Factor

  • Single Fan



Specifications





GPU



RX 570, 14 nm FinFET



4th Graphics Core Next (GCN)



Engine Clock



Up to 1244 MHz, Boost



Stream Processors



2048



Memory Size/Bus



8GB GDDR5/256-bit



Memory Clock



6000 MHz effective



Displays



Maximum 3 Outputs



Interface



PCI-Express 3.0



Resolution




  • DisplayPort: 5120×2880@60Hz

  • HDMI: 4096×2160@60Hz

  • DVI:2560x1600@60Hz



Output




  • 1x DVI-D

  • 1x HDMI

  • 1x DisplayPort 1.4





BIOS Support




  • UEFI



API




  • OpenGL® 4.5

  • OpenCL 2.0

  • DirectX® 12

  • Shader Model 5.0



Game Index



1080p gaming



Sapphire Features




  • Intelligent Fan Control III

  • Long Life Capacitor

  • Fuse protection



AMD Features




  • Radeon™ VR Ready Premium

  • Radeon™ Software

  • Radeon™ FreeSync Technology

  • AMD LiquidVR™ Technology

  • 4th Gen GCN Architecture

  • Radeon™ Chill

  • Radeon™ ReLive DirectX® 12 Technology

  • AMD Eyefinity Technology (Gaming)

  • AMD App Acceleration

  • AMD CrossFire™ Technology

  • AMD CrossFire™ (Bridgeless)

  • 3rd Gen 14nm Process Technology

  • OpenCL 2.0

  • OpenGL 4.5

  • AMD PowerTune Technology

  • TrueAudio Next

  • Unified Video Decoder (UVD)

  • Video Code Engine (VCE)

  • Virtual Super Resolution

  • The Vulkan® API



Cooling



Single fan



Form Factor




  • 2 Slots, ITX

  • Dimension: 170(L)X112(W)X36(H)mm



Power Consumption



<150W



OS



Windows®  10, Windows®  7, 64bit operating system required



System Requirement




  • 500 Watt or greater power supply (Recommended)

  • 1 x 6-pin Power Connector

  • PCI Express® 2.0 or higher version based PC is required with one X16 lane graphics slot available on the motherboard in order for the card to be compatible with.
