D-Link PowerLine DHP-W311AV 500Mbps Wireless Starter Kit with N300 Extender

Brand: D-Link
Product Code: 100598
Availability: In Stock
Status: Brand New
Warranty: One Year RTB Warranty
Manufacturer Url: http://www.dlink.com/uk/en/home-solutions/connect_us/powerline/dhp-w311av-powerline-av-500-wireless-n--starter-kit

Price: $189.75 Gst Inclusive $165.00 Gst Exclusive

D-Link Part No.: DHP-W311AV



Quick Overview



The DHP-W311AV PowerLine AV 500 Wireless N Mini Starter Kit allows you to extend your existing home network to enjoy high-speed and reliable connectivity throughout your home. The PowerLine AV 500 Wireless N Mini Extender features both wireless and PowerLine. This allows you to benefit from PowerLine networking, compliant with the HomePlug AV standard that uses your existing home electrical wiring to extend your home network. The wireless ability allows you to increase the area in your home where you can use your wireless devices.



Data transmission over electrical wiring



The D-Link DHP-W311AV PowerLine AV 500 Wireless N Mini Starter Kit, compliant with the HomePlug AV standard, uses your home's existing electrical wiring to create a network or extend your existing network. It turns every power outlet into a potential network connection to access digital media devices, game consoles, print servers, computers, and network storage devices throughout your home. Additionally, Wireless N provides high speed transfers without the need for unsightly network cables.



Faster wireless speeds and wider operational range



The Wireless N Technology incorporated into this PowerLine product offers increased speed and range beyond standard 802.11g technology. Initial wireless setup can be accomplished quickly, thanks to a convenient setup wizard. WPA and WPA2 encryption keep your network traffic safe and secure.



Ideal for bandwidth intensive applications



This kit is capable of delivering PowerLine AV 500 data transfer rates of up to 500 Mbps and Wireless N speeds of up to 300 Mbps. This rapid transmission speed makes it ideal for bandwidth-intensive applications, guaranteeing smooth HD video streaming, clear VoIP calls, and lag-free online gaming experiences. In addition, it prioritizes Internet traffic, ensuring that multimedia applications do not experience glitches while web surfing and downloads are in progress. This device provides ample network bandwidth, enabling digital home consumers to tap into existing electrical wiring for high-quality multimedia streaming.



Convenient setup and secure operation



The DHP-W311AV plugs directly into a power outlet, and does not require any additional cables. Extend your home network by connecting multiple devices to the farthest corners of your home via Ethernet cable or Wireless N. For convenient setup, wired or wireless encryption keys can be quickly configured with the push of a button on top of the device. The adapter implements 128-bit AES data encryption to protect your network from unauthorised access. With hassle-free 'plug and play' installation, the DHP-W311AV is an ideal solution to create a wall-to-wall home network.



Specifications



Standards

IEEE 802.3

IEEE 802.3u

HomePlug AV

IEEE 1901



PowerLine interface

Power plug (country-dependent)



Ethernet interface

10/100BASE-TX Ethernet port with Auto MDI/MDIX

RJ-45 connector



Input Power

100V ~ 240V, 50/60 Hz

6 W maximum



PowerLine modulation scheme

OFDM symbol modulation



PowerLine frequency band

2 MHz to 30 MHz



Data rates

PowerLine: up to 500 Mbps (PHY rate)

Ethernet: 10/100 Mbps (auto negotiation)



Security

128-bit AES link encryption



Minimum system requirements (For PC Utility Software)

Windows 7/Vista/XP SP3

Ethernet interface (100 Mbps)



LEDs

Power

PowerLine

Ethernet



Dimensions (H x L x W)

90 x 65 x 50 mm (each adapter)



Weight

174.8 g (EU, DHP-W310AV)

185.7 g (UK, DHP-W310AV)

110.7 g (DHP-308AV)



Operating temperature

0 to 40 ?C

Operating humidity

10% to 90% non-condensing



Certifications

FCC

CE EMC Class B

UL

CE LVD
